Technical Specs

Supported devices

Hardware

IP Cameras, DVR, NVR, Decoders, Access Control, I/O devices, IP keyboar, USB keyboard.

Search and setups

Easy to seach and full range of NVR &IP camera functions configuration

Protocol Supported

Tbvision, ONVIF profile S, RTSP, PISA

Live view/Preview functions

Live view/Preview video

Max 64 simultaneous live display (per monitor) Multi-screen supported 1x1, 2x2, 3x3, 4x4, 8x8 -window division for live view

Group Tour, Sequence Switching, Group Select on Alarm

Real time alarm pop-up

Local Recording and Snap Shot Function

Video optimization (Brightness control, saturation, hue)

Main, sub-stream selectable and full electronic channel amplification

System performance indicator

Playback

Play forward in selectable speed, pause, stop, fast and slow play. Timeline search and date/time search

Export video clips

Snapshot from playback function supported

Digital zoom function in playback (Mouse wheel)

Alarm Management

Alarm input types

External NVR or camera input, motion detection, video loss, video detection, access control events

Link alarms to

Audio map, TV wall, image pop-up, video, snapshot, PTZ control

Video Analytics (Optional)

Smoke and Fire

To detect smoke and fire in camera field of view

Face Recognition

To arrange for controlled automated access of persons to the premises

Face Detection

To detect a face and enter it into a database

Loud Sound Detection

To register noise level surpassing the preset limit

People Counting

To perform visitor counting

License Plate Recognition

To arrange for controlled automated access of cars to the premises

Heat Map

To monitor routes of moving and stopping of visitors, evaluate people flow intensity

Abandoned Object

To detect an abandoned object and find a person who left it

Tracking

To perform perimeter control of selected area, border, or line

Crowd Monitoring

To count people in a crowd, to notify about crossing of a preset threshold

Behavior analysis

Fighting, Fall down

Smart Analysis

Target track Cross Border Guard object Face detect Tripwire

Left obstacle Direction

Motion detection

To motion by human

Local Recording

Recoding mode

Continuous recording, Recording by system event, Recording by camera motion sensor, Scheduled recording with the 5 ability to combine recording modes, Recording by operator’s command.

Compression standard

H.265+/H.265/H.264+/H.264/MPEG4/MJPEG

Device recoding

SAN, NAS, IPSAN Record, USB

Local storage

Support local PC video storage, alarm, timing, manual, motion detection

Video Search

Time, Event

System LOG

LOG

Alarm, Operations log, Remote configuration log

User management

Login

Supports multi-user login and

configuration (Operate, Guest, Administrator), data backup management (Ability to grant access rights, prevent backup, nauthorized distribution)

Remote access to your CCTV system

To get remote access to your video surveillance system, you can use through web client via the browser to live view and setup via LAN local, internet. Video stream formats supported by clients: MJPEG, MPEG-4, MxPEG, H.264, H.265 and any versions of operating systems.

Permissions

Camera lights

PTZ control, setup

Playback Rights, Local, Remote and Edge Recording

Audio Rights

Remote Configuration (NVR/Camera) Rights

Watermasking

Yes

OSD Configuration

Device Name, Channel ID, Channel Name, Time, Custom OSD

Decoding video wall

Video wall

64/32/16/9/4/1 Split Control

Supports sequence tour, group tour, live, playback and PTZ control on video wall

Configurable matrix style according to screen layout.

Operating System

Operating System

Windows   7, 8, 10 , 11        32/64bit ,   Window Server

Language

English,Vietnam
