· Three Dimensional Joystick Control of PTZ Functions
· Preset Position, Auto Scan, Auto Pan, Auto Tour & Pattern Auxiliary Functions
· On-Screen Menu & User Operation Procedure Tips
· Three Dimensional Joystick Control of PTZ Functions
· Preset Position, Auto Scan, Auto Pan, Auto Tour & Pattern Auxiliary Functions
· On-Screen Menu & User Operation Procedure Tips
Specifications
|
Technical Specifications |
|
|
Joystick |
3-axis, vector-solving, with twisting, return to-center head |
|
Keyboard Connector |
RJ-45, RS232, RS485, RS422, USB |
|
Keyboard |
Direct Mode, Network Mode |
|
Communication |
Interface: RS232/RS485 |
|
Direct Mode |
DVR Protocol: VEILUX Dome Protocol: VEILUX/PELCO-D/PELCO-P/PELCO-D1/PELCO-P, etc |
|
Network Mode |
Interface: RJ45 DVR/Network Dome: IP Address/Port/Protocol |
|
Display |
LCD 128 x 64 pixel screen |
|
Power Supply |
Power adapter, input 100V~240V 50Hz/60Hz, output DC12V/1000mA |
|
Power Consumption |
5W |
