· Access of 4 HD TVI cameras with up to 1080p resolution.
· Pluggable dummy HDD for HDD with up to 2 TB capacity.
· User-friendly GUI providing easy and flexible operations.
· Pluggable 4G module and Wi-Fi module providing flexible data transmission solutions.
· Built-in GPS module precisely positioning the vehicle via the satellite and recording the location information in the video stream.
· Information collection interfaces collecting driving information such as left/right turn, braking, reversing, etc.
· Specialized aviation connectors ensuring signal stability.
Specifications
|
Video/Audio Input |
Analog Camera |
4-ch HIK wiring sequence analog camera, Max. 1080P |
|
Two-way Audio |
1, integrated in EXT.DEV interface |
|
|
Video/Audio Output |
Video Output |
Main output: 1, integrated in EXT.DEV interface |
|
VGA: 1 |
||
|
Audio Output |
1 |
|
|
Encoding/Decoding Parameters |
Video Compression |
H.264/H.265 |
|
Encoding Resolution |
Main stream: 1080p/720p/WD1/4CIF Sub-stream: 720P/WD1/4CIF/2CIF/CIF |
|
|
Frame Rate |
PAL: 1 to 25 fps; NTSC: 1 to 30 fps |
|
|
Audio Compression |
G.711a/G.711u/G.722.1/G.726 |
|
|
Stream Type |
Video, video & audio |
|
|
Audio Bitrate |
16 Kbps |
|
|
Dual Stream |
Supported |
|
|
Storage |
HDD/SSD |
2 × 2.5 inch HDD/SSD, up to 2 TB for each HDD/SSD HDD/SSD data can be exported locally via this converter (optional) (A dummy HDD with 2 HDD/SSDs can be extended; Not for baseline. Note the SD card capacity when ordering) |
|
SD Card |
1 × SD card, up to 256 GB（not for baseline. Note the SD card capacity when ordering） |
|
|
Wireless Network |
4G Dialing |
1 × 4G card slot, 1 ×FAKRA antenna |
|
Available Module |
5G module(optional) |
|
|
Wi-Fi |
WI58 model: 2 × 5.8 G Wi-Fi SMA antenna (Optional. 802.11B/G/N and 802.11AC are selectable. 1 antenna is needed for 802.11B/G/N module. 2 antennas are needed for 802.11AC module.) |
|
|
Positioning |
GNSS (Global Navigation Satellite System) |
GPS (Global Positioning System) & GLONASS (Global Navigation Satellite System), 1 ×FAKRA antenna |
|
External Interface |
Network Interface |
● Front panel :1 ×10M/100M RJ45 ● Rear panel: 1 × 10M/100M M12 6-pin aviation connector Note：The front and rear network ports are at different network segments and the 6-pin aviation network cable female head to RJ45 is optional. |
|
Serial Port |
2 × RS-232(harness is optional), 1 × RS-422 (integrated in EXT.DEV interface) |
|
|
USB Interface |
● Front panel: 1 × USB 2.0 ● Rear panel: 1 × USB 2.0 (5-pin aviation connector) |
|
|
Sensor-in |
4 high/low level signal inputs |
|
|
Alarm Input |
4 high/low level signal inputs, 1 pulse signal input, 1 BUTTON input |
|
|
General |
Alarm Output |
2 relay signal outputs |
|
Operating Method |
Mouse, IR remote control, Web control, and touchscreen |
|
|
AI Function |
Abnormal Detection |
|
|
G-sensor |
Built-in |
|
|
Remote Control |
Optional |
|
|
Power Supply |
+9 to +36 VDC |
|
|
Consumption |
Standby: ≤ 0.5 W Full load: ≤ 45 W |
|
|
|
|
Note: Without peripheral and storage media ≤ 20 W |
|
Working Temperature |
-10 °C to +60 °C (+14 °F to +140°F) |
|
|
Working Humidity |
10% to 95% |
|
|
Device Dimension (W × D × H) |
206 × 225.4 × 60.1 mm (8.1 × 8.87 × 2.37 inch) |
|
|
Device Weight (Without Storage Media) |
1.7 kg (3.75 lb) |
