l Adopts progressive scan CMOS to prevent motion image aliasing
l Supports HD coaxial output with the resolution 1080p
l Min. illumination: 0.1 Lux @(F1.2, AGC ON), 0 Lux with IR
l Supports auto day & night switch
l Adopts auto electronic shutter to adapt to different environment
l Supports auto gain control and self-adaption to light
l Adopts built-in mic and supports audio input
l Shock-proof design and aviation output plug
Specifications
|
Camera |
|
|
Image Sensor |
Progressive Scan CMOS |
|
Resolution |
High quality imaging with 2 MP (1920x1080) |
|
Min. Illumination |
0.1 Lux @ (F1.2, AGC ON), 0 Lux with IR |
|
Shutter Time |
1/25 s to 1/50,000 s |
|
FOV |
2.1 mm, horizontal FOV 117°, vertical FOV 66°, diagonal FOV 143° 2.8 mm, horizontal FOV 96°, vertical FOV 51°, diagonal FOV 115° 3.6 mm, horizontal FOV 75°, vertical FOV 44°, diagonal FOV 90° |
|
Lens |
2.1mm, 2.8mm, 3.6mm |
|
Lens Mount |
M12 |
|
Angle |
Horizontal: 0 to 60°, vertical: 0 to 50°, rotate: 0 to 360° |
|
Day & Night |
Electronic |
|
Frame Rate |
1080p @25fps |
|
Synchronization |
Internal |
|
S/N Ratio |
42 dB |
|
Interface |
|
|
Video Output |
1, Vp-p Composite Output (aviation plug) |
|
Audio Input |
Build-in MIC |
|
Audio Output |
1, aviation plug (linear resistance: 1 kΩ) |
|
Aviation Pin Order |
1: Video, 2: Audio, 3: Power, 4: Grounding |
|
General |
|
|
Working Temperature |
-40 °C to 75 °C (-40 °F to 167 °F) |
|
Working Humidity |
≤ 90% |
|
Power Supply |
9 to 16 VDC |
|
Power Consumption |
Max. 2.2 W |
|
IR Distance |
10 m |
|
Dimension |
74 mm × 64.5 mm × 71.1 mm (2.9" × 2.5" × 2.8") |
|
Weight |
200 g (0.44 lb.) |
