TB-SW12P12S-L2 is 24*10/100/1000 Base-T ports, 4*100/1000Base-X SFP ports, 1 Console port. Switch has powerful ACL functions to access and control L2-L7 data, providing carriers flexible and various policy control methods.
With high level lightning protection and wide working temperature range makes it a better performance in outdoor or harsh environment.
Support static routing, policy routing, rip, OSPF and other three-layer routing protocols
Supports IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z and IEEE 802.3ab standard.
Support DHCP Server, DHCP Relay, DHCP Snooping
|
Specitications |
|
||
|
Port Number |
24 Gigabit electrical ports and 4 Gigabit SFP optical ports |
|
|
|
Forwarding Mode |
Store-and-forward switching |
|
|
|
MAC Address Table |
8 K |
|
|
|
Switching Capacity |
336 Gbps |
|
|
|
Packet Forwarding |
51 Mpps |
|
|
|
Ethernet Port |
24 * 10/100/1000Base-T ports, 4 * 100/1000Base-X SFP ports (1.25G 1310/1550nm,20km,LC, Single-mode), 1 Console port |
|
|
|
Device Maintenance |
|
|
|
|
Reliability |
Support STP/RSTP/MSTP |
|
|
|
VLAN |
|
|
|
|
Routing |
|
|
|
|
QoS |
|
|
|
|
Multicast |
|
|
|
|
Ethernet Port |
24 * 10/100/1000Base-T ports, 4 * 100/1000Base-X SFP ports (1.25G 1310/1550nm,20km,LC, Single-mode), 1 Console port |
|
|
|
Security |
|
|
|
|
General |
|||
|
Shell |
Iron shell, Fan less design |
||
|
Weight |
2.25 kg (4.85 lb) |
||
|
Dimension (W × H × D) |
440 mm × 44 mm × 210 mm |
||
|
Operating temperature |
-30 °C to 65 °C (-22 °F to 149°F) |
||
|
Storage temperature |
-40 °C to 75 °C (-40 °F to 167 °F) |
||
|
Operating humidity |
10% to 95% (no condensation) |
||
|
Storage humidity |
5% to 95% (no condensation) |
||
|
Power supply |
AC: 100V-240V, 50/60Hz |
||
|
Power consumption in idle |
20 W |
||
